Chain-type Stone Turnover Machine
product introduction
The Chain - type Stone Turnover Machine is an essential piece of equipment in the stone - working industry. It features a robust grey base and bright yellow turnover arms connected by sturdy chains. This machine is engineered to handle the rotation of stone slabs with ease and precision.
Thanks to its advanced chain - driven mechanism, it ensures smooth and stable turnover of heavy stone slabs, reducing the risk of damage. The machine can rotate stone slabs to the desired angle, which is crucial for various processing tasks like polishing, cutting, and inspection. Its user - friendly design allows for straightforward operation, and the durable construction guarantees long - term reliability, making it a valuable asset for stone processing plants and related industries.
product advantage
• Efficient Operation: The chain - driven system enables smooth and rapid rotation of stone slabs, significantly reducing the time required for re - positioning during processing, thus enhancing overall work efficiency.
• Sturdy Build: With a robust grey base and durable yellow turnover arms, it can withstand the weight of heavy stone slabs, ensuring long - term reliability and minimal risk of structural failure.
• Precise Positioning: It allows for accurate control over the rotation angle of stone slabs, which is crucial for tasks such as precise cutting, polishing, and inspection, ensuring high - quality processing results.
• Safety Assurance: The design minimizes the need for manual handling of heavy slabs during rotation, reducing the risk of worker injury and slab damage.
• Versatility: Suitable for a wide variety of stone slab sizes and types, it can be applied in different stages of stone processing, from initial shaping to final finishing.
technical data
| MODEL | MAX LOAD CAPACITY | MAX BLOCK SIZE(L×W×H） | TURNING DEGREE | POWER OF MAIN MOTOR | NET WEIGHT |
| XGM-10T | 10000kg | 2400x1500x1600mm | 0-90° | 3kw | 1500kg |
| XGM-35T | 35000kg | 3000x1600x2000mm | 0-90° | 3kw | 3500kg |
| XGM-45T | 45000kg | 3500x1600x2000mm | 0-90° | 5.5kw | 4500kg |
| XGM-65T | 65000kg |
3500x1600x2000mm | 0-90° | 7.5kw |
5200kg |
PACKAGING & SHIPPING
• For urgent orders with lighter weight or samples, we recommend using express delivery.
• For regular orders weighing over 45kgs, air cargo is recommended.
• For large diameter saw blades or heavy items, shipping by sea is recommended.
Xingong will provide recommendations based on the specific requirements of each order.
